About product
Product description:Screw pile are used for new construction to support existing structures. They are designed for applications in expansive soils, high water tables, fill areas, and other areas where unstable soils require a deep foundation. In compression they are used as footers and in tension they may be used to support retaining or foundation walls. Helical pilers are round or square, tubular or bar steel shafts with round helix plates welded to them.
Product features:
1.Helix blade configuration selected to achieve design depth and capacity
2.Can be installed in areas of limited or tight access
3.Installs quickly.
4.Installation does not generate spoils.
5.Vibration-free installation (unlike driven piles)
6.Concrete can be poured immediately following pile installation
7.Available with optional hot-dip galvanizing for added corrosion protection
8.Cost-competitive compared to other deep foundation alternatives.
9.Call or contact us online for a for new construction helical piles estimate.
10.Supports soil stabilization.
Product superiority:
1.Bar Material: 40Cr or 45# steel, round corner 5mm radius
2.Helix Plate material conforms to ASTM A36 hot rolled plate
3.helices thickness are available in 3/8" and 1/2" inch
4.All helix leading edges sharpened and rock cut and 45 degrees.
5.Corrosion protection to conform to ASTM A153 standard for hot dipped zinc coating
6.A better conventional solid steel extra high strength helical screw pile
7.Welded coupling for greater strength. Eliminates shaft heat damage caused by upset coupling process.
Product specification:
| Specifications |
| Size | Lead Length (ft) | Helix Size (inch) | Extension Length(ft) |
| 1 1/2" | 3ft/5ft/7ft | 8/10/12/14 | 3ft/5ft/7ft/10ft |
| 2" | 3ft/5ft/7ft | 8/10/12/14 | 3ft/5ft/7ft/10ft |
| 3" | 3ft/5ft/7ft/10ft | 8/10/12/15 | 3ft/5ft/7ft/10ft |
Notes: Different materials and specifications can be customized according to your demands.
About shipping and logistics
We have a well-established logistics system, and we provide comprehensive services from the time of production to the port of shipment.
About us
Qingdao KXD Steel Structure Co., Ltd, is a professional enterprise specializing in designing, detailing, manufacturing, and constructing high quality steel structures, prefabricated houses and container houses. Our company offers you various kinds of steel constructions, which would meet all your requirements.
Our company are professionally engaged in steel structure design,manutacture and installation. Our specialists have extensive experience in working with different type constructions. Steel constructions are manufactured by using drawing tools, in accordance with customers' all requirements and quality standards.
Our aim is highest quality, competitive price, and best service to satisfy our customers, we will always keep on creating and innovation, build a best credibility and highest reputation company in the world.Welcome to visit us.
